Analyse your simulation output using non-compartmental analysis.
Install the latest stable release as follows:
devtools::install_github("Calvagone/campsisnca")First import the campsisnca and gtsummary
packages as follows:
library(campsisnca)
library(gtsummary)
library(gt)Assume some results were simulated with Campsis (see
campsis dataframe) :
campsis <- campsisnca::pk_bolus_md
campsis## # A tibble: 5,000 × 16
## ID TIME ARM A_DEPOT A_CENTRAL A_PERIPHERAL A_OUTPUT BW CL V2
## <dbl> <dbl> <dbl> <dbl> <dbl> <dbl> <dbl> <dbl> <dbl> <dbl>
## 1 1 0 0 0 0 0 0 93.6 5.89 94.8
## 2 1 1 0 4.31e+2 538. 11.3 19.4 93.6 5.89 94.8
## 3 1 2 0 1.86e+2 722. 32.4 59.7 93.6 5.89 94.8
## 4 1 4 0 3.44e+1 741. 71.7 153. 93.6 5.89 94.8
## 5 1 6 0 6.39e+0 657. 96.3 240. 93.6 5.89 94.8
## 6 1 8 0 1.19e+0 574. 108. 316. 93.6 5.89 94.8
## 7 1 12 0 4.09e-2 447. 110. 442. 93.6 5.89 94.8
## 8 1 16 0 1.41e-3 358. 99.8 542. 93.6 5.89 94.8
## 9 1 24 0 1.67e-6 239. 72.7 688. 93.6 5.89 94.8
## 10 1 48 0 1.67e-6 316. 96.4 1588. 93.6 5.89 94.8
## # ℹ 4,990 more rows
## # ℹ 6 more variables: Q <dbl>, V3 <dbl>, KA <dbl>, CP <dbl>, OBS_CP <dbl>,
## # Y <dbl>
Let’s define our PK metrics at Day 1 and Day 7 as follows:
# Day 1
nca_d1 <- NCAAnalysis(name = "Day 1", window = TimeWindow(0, 24), variable = "Y") %>%
add(c(AUC(unit = "ng/mL*h"), Cmax(unit = "ng/mL"), Tmax(unit = "h"), Ctrough(unit = "ng/mL")))
# Day 7
nca_d7 <- NCAAnalysis(name = "Day 7", window = TimeWindow(144, 168), variable = "Y") %>%
add(c(AUC(), Cmax(), Tmax(), Ctrough()))These 2 metrics may be imported into a metrics table object, as
follows. Use the calculate method to calculate the metrics
in the table.
table <- NCATable() %>%
add(c(nca_d1, nca_d7)) %>%
calculate(campsis)This table can be exported:
export function:table %>% export(dest = "dataframe")## # A tibble: 24 × 4
## metric stat value analysis
## <chr> <chr> <dbl> <chr>
## 1 AUC median 134. Day 1
## 2 AUC p5 102. Day 1
## 3 AUC p95 168. Day 1
## 4 Cmax median 10.2 Day 1
## 5 Cmax p5 7.85 Day 1
## 6 Cmax p95 13.1 Day 1
## 7 tmax median 2 Day 1
## 8 tmax p5 1 Day 1
## 9 tmax p95 6 Day 1
## 10 Ctrough median 2.89 Day 1
## # ℹ 14 more rows
When type is not specified, default value is
summary. Argument type can also be
summary_wide or summary_pretty. In the latter
case, summary statistics are exported according to the arguments
stat_display and digits provided for each
metric.
gt:table %>% export(dest = "gt") %>% as_raw_html()| Metric |
Day
1 N = 2001 |
Day
7 N = 2001 |
|---|---|---|
| 1 Median (5% Centile–95% Centile) | ||
Please note the individual metrics can also be exported to a
dataframe using the export function as follows:
table %>% export(dest = "dataframe", type = "individual_wide")## # A tibble: 400 × 6
## id analysis AUC Cmax tmax Ctrough
## <dbl> <chr> <dbl> <dbl> <dbl> <dbl>
## 1 1 Day 1 122. 9.78 4 2.75
## 2 2 Day 1 92.6 6.11 6 1.70
## 3 3 Day 1 119. 10.9 2 1.97
## 4 4 Day 1 131. 9.72 2 1.99
## 5 5 Day 1 166. 10.1 4 3.79
## 6 6 Day 1 152. 10.1 2 3.04
## 7 7 Day 1 134. 9.28 2 2.70
## 8 8 Day 1 163. 13.7 2 2.91
## 9 9 Day 1 111. 9.62 2 1.94
## 10 10 Day 1 118. 9.91 4 2.90
## # ℹ 390 more rows
library(dplyr)
campsis_ <- campsis %>%
mutate(Scenario = ifelse(BW >= 75, ">=75kg patients", "<75kg patients"))
day1 <- NCAAnalysis(name = "Day 1", window = TimeWindow(0, 24), variable = "Y", strata = c(Scenario = "all")) %>%
add(c(AUC(unit = "ng/mL*h"), Cmax(unit = "ng/mL"), Tmax(unit = "h"), Ctrough(unit = "ng/mL")))
day7 <- NCAAnalysis(name = "Day 7", window = TimeWindow(144, 168), variable = "Y", strata = c(Scenario = "all")) %>%
add(c(AUC(), Cmax(), Tmax(), Ctrough()))
table <- NCATable() %>%
add(c(day1, day7)) %>%
calculate(campsis_)
table %>% export(dest = "gt") %>% as_raw_html()| Metric |
>=75kg
patients N = 971 |
<75kg
patients N = 1031 |
|---|---|---|
| Day 1 | ||
| Day 7 | ||
| 1 Median (5% Centile–95% Centile) | ||
# Alternatively, first stratification variable can be seen in columns (use of 'tbl_merge' within gtsummary)
table <- NCATable(combine_with = "tbl_merge") %>%
add(c(day1, day7)) %>%
calculate(campsis_)
table %>% export(dest = "gt") %>% as_raw_html()|
>=75kg
patients N = 971 |
<75kg
patients N = 1031 |
>=75kg
patients N = 971 |
<75kg
patients N = 1031 |
|
|---|---|---|---|---|
| 1 Median (5% Centile–95% Centile) | ||||
nca <- NCAAnalysis(variable = "Y") %>%
add(c(Thalf.2cpt.dist(), Thalf.2cpt.eff(), Thalf.2cpt.z()))
table <- NCATable() %>%
add(nca) %>%
calculate(campsis %>% mutate(DOSE = 1000, TAU = 24))
table %>% export(dest = "gt") %>% as_raw_html()| Metric | N = 2001 |
|---|---|
| 1 Median (5% Centile–95% Centile) | |
nca <- NCAAnalysis(variable = "Y") %>%
add(c(Thalf(window = TimeWindow(7 * 24, 10 * 24))))
table <- NCATable() %>%
add(nca) %>%
calculate(campsis)
table %>% export(dest = "gt") %>% as_raw_html()| Metric | N = 2001 |
|---|---|
| 1 Median (5% Centile–95% Centile) | |
# Day 1
nca_d1 <- NCAAnalysis(name = "Day 1", window = TimeWindow(0, 24), variable = "Y") %>%
add(AUC(digits = ~ style_sigfig(.x, 2), name = "AUC1")) %>% # At least 2 significant figures (default in gtsummary)
add(AUC(digits = c(1, 2, 2), name = "AUC2")) %>% # Respectively 1/2/2 digit(s) after decimal for med, p5 and p95
add(AUC(digits = ~ signif(.x, 2), name = "AUC3")) %>% # 2 significant digits only
add(AUC(digits = list(~ round(.x / 5) * 5, ~ round(.x, 1), ~ style_number(.x)), name = "AUC4")) # 1 specific function for med, p5 and p95
# Day 7
nca_d7 <- NCAAnalysis(name = "Day 7", window = TimeWindow(144, 168), variable = "Y") %>%
add(AUC(name = "AUC1")) %>%
add(AUC(name = "AUC2")) %>%
add(AUC(name = "AUC3")) %>%
add(AUC(name = "AUC4"))
table <- NCATable()
table <- table %>%
add(c(nca_d1, nca_d7)) %>%
calculate(campsis)
table %>% export(dest = "gt") %>% as_raw_html()| Metric |
Day
1 N = 2001 |
Day
7 N = 2001 |
|---|---|---|
| 1 Median (5% Centile–95% Centile) | ||
# Compute Cmax yourself using campsisnca
custom1 <- CustomMetric(fun = ~ Cmax() %>% i_value(.x, .y), name = "C_{max} custom", unit = "ng/mL")
# Check if Cmax if higher than 12 ng/mL
custom2 <- CustomMetric(
fun = ~ (Cmax() %>% i_value(.x, .y)) > 12,
name = "C_{max} > 12",
unit = "%",
categorical = TRUE
)
# Shortcut notation is also accepted
custom3 <- CustomMetric(fun = ~ Cmax > 13, name = "C_{max}> 13", unit = "%", categorical = TRUE)
# Day 1
nca_d1 <- NCAAnalysis(name = "Day 1", window = TimeWindow(0, 24), variable = "Y") %>%
add(c(Cmax(unit = "ng/mL"), Tmax(unit = "h"), custom1, custom2, custom3))
# Day 7
nca_d7 <- NCAAnalysis(name = "Day 7", window = TimeWindow(144, 168), variable = "Y") %>%
add(c(Cmax(), Tmax(), custom1, custom2, custom3))
table <- NCATable()
table <- table %>%
add(c(nca_d1, nca_d7)) %>%
calculate(campsis)
table %>% export(dest = "gt") %>% as_raw_html()| Metric |
Day
1 N = 2001 |
Day
7 N = 2001 |
|---|---|---|
| 1 Median (5% Centile–95% Centile); n / N (%) | ||
# Alternatively, all dichotomous levels can be shown as well:
table <- NCATable(show_all_levels = TRUE)
table <- table %>%
add(c(nca_d1, nca_d7)) %>%
calculate(campsis)
table %>% export(dest = "gt") %>% as_raw_html()| Metric |
Day
1 N = 2001 |
Day
7 N = 2001 |
|---|---|---|
| 1 Median (5% Centile–95% Centile); n / N (%) | ||
nca <- NCAAnalysis(variable = "Y") %>%
add(c(
AUC(unit = "ng/mL*h", stat_display = "{geomean} ({geocv}%)"),
Cavg(unit = "ng/mL", stat_display = "{geomean} ({geocv}%)")
))
table <- NCATable() %>%
add(nca) %>%
calculate(campsis)
table %>% export(dest = "gt") %>% as_raw_html()| Metric | N = 2001 |
|---|---|
| 1 geomean (geocv%) | |
get_category <- function(.x, .y) {
values <- Cmax() %>% i_value(.x, .y)
retValue <- dplyr::case_when(
values < 10 ~ "(1) < 10 ng/mL",
values >= 10 & values <= 15 ~ "(2) 10-15 ng/mL",
values > 15 ~ "(3) > 15 ng/mL",
)
return(retValue)
}
# Or equivalently, the 1-line purrr-style lambda expression
# get_category <- ~case_when(Cmax < 10 ~ "(1) < 10 ng/mL", Cmax >= 10 & Cmax <= 15 ~ "(2) 10-15 ng/mL", Cmax > 15 ~ "(3) > 15 ng/mL")
# Day 1
nca_d1 <- NCAAnalysis(name = "Day 1", window = TimeWindow(0, 1, time_unit = "day"), variable = "Y") %>%
add(Cmax(unit = "ng/mL")) %>%
add(CustomMetric(fun = get_category, name = "C_{max} categories", unit = "%", categorical = TRUE))
# Day 7
nca_d7 <- NCAAnalysis(name = "Day 7", window = TimeWindow(6, 7, time_unit = "day"), variable = "Y") %>%
add(Cmax()) %>%
add(CustomMetric(fun = get_category, name = "C_{max} categories", unit = "%", categorical = TRUE))
table <- NCATable()
table <- table %>%
add(c(nca_d1, nca_d7)) %>%
calculate(campsis)
table %>% export(dest = "gt") %>% as_raw_html()| Metric |
Day
1 N = 2001 |
Day
7 N = 2001 |
|---|---|---|
| 1 Median (5% Centile–95% Centile); n / N (%) | ||
In the example below, we look at the individual time above (or below) 10 ng/mL at Day 1 for the 10 first subjects.
day1 <- campsis %>%
timerange(0, 24) %>%
filter(ID %in% (1:10))
campsis::spaghettiPlot(day1, "Y") +
ggplot2::geom_hline(yintercept = 10, linetype = "dashed", color = "red")
nca <- NCAAnalysis(window = TimeWindow(0, 24), variable = "Y") %>%
add(Cmax(unit = "ng/mL*h", stat_display = "{mean}")) %>%
add(TimeAboveLimit(limit = 10, unit = "h", stat_display = "{mean}")) %>%
add(TimeBelowLimit(limit = 10, unit = "h", stat_display = "{mean}"))
table <- NCATable() %>%
add(nca) %>%
calculate(campsis %>% filter(ID %in% (1:10)))
table %>% export(dest = "dataframe", type = "individual_wide")## # A tibble: 10 × 4
## id Cmax `Time above 10` `Time below 10`
## <dbl> <dbl> <dbl> <dbl>
## 1 1 9.78 0 24
## 2 2 6.11 0 24
## 3 3 10.9 0.829 23.2
## 4 4 9.72 0 24
## 5 5 10.1 0.427 23.6
## 6 6 10.1 0.186 23.8
## 7 7 9.28 0 24
## 8 8 13.7 4.94 19.1
## 9 9 9.62 0 24
## 10 10 9.91 0 24
Summary statistics can also be exported:
table %>% export(dest = "gt") %>% as_raw_html()| Metric | N = 101 |
|---|---|
| 1 Mean | |
Let’s generate some fictitious results where two treatment arms are
simulated (1g QD and 2g QD) and where
scenarios are included too (Base scenario and
Lower clearance).
library(campsis)
arm1 <- Arm(subjects = 24, label = "1g QD") %>%
add(Bolus(time = 0, amount = 1000, compartment = "ABS", ii = 24, addl = 6)) %>%
add(Observations(seq(0, 14 * 24, by = 0.1))) # 2-weeks observations
arm2 <- Arm(subjects = 24, label = "0.5g BID") %>%
add(Bolus(time = 0, amount = 500, compartment = "ABS", ii = 12, addl = 13)) %>%
add(Observations(seq(0, 14 * 24, by = 0.1))) # 2-weeks observations
dataset <- Dataset() %>%
add(c(arm1, arm2))
scenario1 <- Scenario(name = "Base scenario", model = ~.x, dataset = ~.x)
scenario2 <- Scenario(
name = "Lower clearance",
model = ~ .x %>%
replace(Theta(name = "CL", value = 2)),
dataset = ~.x
)
scenarios <- Scenarios() %>% add(c(scenario1, scenario2))
results <- simulate(
model = model_suite$pk$`2cpt_fo`,
dataset = dataset,
seed = 1,
dest = "mrgsolve",
scenarios = scenarios
)
shadedPlot(results, "CONC", colour = "ARM", strat_extra = "SCENARIO") +
ggplot2::facet_wrap(~SCENARIO) +
ggplot2::xlab("Time (h)") +
ggplot2::ylab("Concentrations (ng/mL)") +
ggplot2::labs(colour = "Arm", fill = "Arm")
NCA summary statistics are automatically calculated across all strata levels in ARM and SCENARIO.
nca <- NCAAnalysis(name = "Day 7", window = TimeWindow(144, 168), variable = "CONC") %>%
add(AUC(unit = "ng/mL*h")) %>%
add(Cmax(unit = "ng/mL")) %>%
add(CustomMetric(
fun = ~ (Cmax() %>% i_value(.x, .y)) > 30,
name = "C_{max} > 30",
unit = "%",
categorical = TRUE
)) %>%
add(Tmax(unit = "h", digits = 2)) %>%
add(Ctrough(unit = "ng/mL")) %>%
add(Thalf(unit = "h", window = TimeWindow(200, "last"))) # Thalf will be estimated by dosing a linear regression on the range [200, 'last']
table <- NCATable() %>%
add(nca) %>%
calculate(results)
table %>% export(dest = "gt") %>% as_raw_html()| Metric |
1g
QD N = 241 |
0.5g
BID N = 241 |
|---|---|---|
| Base scenario | ||
| Lower clearance | ||
| 1 Median (5% Centile–95% Centile); n / N (%) | ||
In the previous example, statistics are summarized on Day 7. In you wish specifics statistics for each one of your arms, you could also proceed sightly differently by creating 2 analyses (1 for each strata) and refer to specific arms by overriding the default strata.
nca_arm1 <- NCAAnalysis(
name = "Last dose in '1g QD' arm",
window = TimeWindow(144, 168),
variable = "CONC",
strata = c(ARM = "1g QD", SCENARIO = "all")
) %>%
add(AUC(unit = "ng/mL*h")) %>%
add(Cmax(unit = "ng/mL")) %>%
add(CustomMetric(
fun = ~ (Cmax() %>% i_value(.x, .y)) > 30,
name = "C_{max} > 30",
unit = "%",
categorical = TRUE
)) %>%
add(Tmax(unit = "h", digits = 2)) %>%
add(Ctrough(unit = "ng/mL")) %>%
add(Thalf(unit = "h", window = TimeWindow(200, "last")))
nca_arm2 <- NCAAnalysis(
name = "Last dose in '0.5 BID' arm",
window = TimeWindow(156, 168),
variable = "CONC",
strata = c(ARM = "0.5g BID", SCENARIO = "all")
) %>%
add(AUC(unit = "ng/mL*h")) %>%
add(Cmax(unit = "ng/mL")) %>%
add(CustomMetric(
fun = ~ (Cmax() %>% i_value(.x, .y)) > 30,
name = "C_{max} > 30",
unit = "%",
categorical = TRUE
)) %>%
add(Tmax(unit = "h", digits = 2)) %>%
add(Ctrough(unit = "ng/mL")) %>%
add(Thalf(unit = "h", window = TimeWindow(200, "last")))
table <- NCATable() %>%
add(nca_arm1) %>%
add(nca_arm2) %>%
calculate(results)
table %>% export(dest = "gt") %>% as_raw_html()| Metric |
Base
scenario N = 241 |
Lower
clearance N = 241 |
|---|---|---|
| Last dose in ‘1g QD’ arm | ||
| Last dose in ‘0.5 BID’ arm | ||
| 1 Median (5% Centile–95% Centile); n / N (%) | ||
These binaries (installable software) and packages are in development.
They may not be fully stable and should be used with caution. We make no claims about them.
Health stats visible at Monitor.
